Environmental Requirements:
Working temperature/Humidity: -10℃~+ 40℃/20%~90%RH
Storage temperature/Humidity: -20℃~+85℃/10%~95%RH
USB Characteristic:
| Serial No. | Parameter | Description |
| 1 | Panel Material | PC 94-V0 |
| 2 | Inside material | Tin phosphorous bronze |
| 3 | Surface finish | Glossy |
| 4 | USB DC output | 2.1A/5V |
| 5 | Output voltage tolerance | ±5% |
| 6 | Output power | Max.18W |
| 7 | Service life in hours | 3000h 18W |
| 8 | Efficiency | 78% |
| 9 | No-load power consumption | Max 0.2W |
| 10 | Input voltage | 100~240v/AC 50~60Hz |
| 11 | Color | White RAL9003 Black |
| 12 | Number of terminals | 1 screw terminals |
| 13 | Electrical insulation class | Class II |
| 14 | IK degree of protection | IK04 |
| 15 | IP degree of protection | IP21 |
| 16 | Dimension of product | 23*36mm |
Application:
1.Feature of Safewire 120/128 type modules:
1.Full range popular socket as Universal , Thailand , NEMA , BS , Italy etc. market.
2.Full range LAN ,HDMI,Audio,Acoustics,XLR/Canon,Dimmer module etc.
3.Package Shoping：modules/socket+adaptor/connector+cable/accessories.
2.Advantage of Safewire 120/128 type modules：
1.Good Quality raw material:
1)Flame Retardant PC plastic：
2)Phosphor copper,excellent conductivity&strong elasticity, 5000 times plug in &out：
