Single Port USB Charging 2.1A PC Plastic 45*22.5mm Socket

Short Description:




  • Port: Wenjiang
  • Technical Parameters

    Product Tags

    Environmental Requirements:

    Working temperature/Humidity: -10~+ 40/20%~90%RH

    Storage temperature/Humidity: -20~+85/10%~95%RH



    USB Characteristic:

    Serial No. Parameter Description
    1 Panel Material PC 94-V0
    2 Inside material Tin phosphorous bronze
    3 Surface finish Glossy
    4 USB DC output 2.1A/5V
    5 Output voltage tolerance ±5%
    6 Output power Max.18W
    7 Service life in hours 3000h 18W
    8 Efficiency 78%
    9 No-load power consumption Max 0.2W
    10 Input voltage 100~240v/AC 50~60Hz
    11 Color White RAL9003 Black
    12 Number of terminals 1 screw terminals
    13 Electrical insulation class Class II
    14 IK degree of protection IK04
    15 IP degree of protection IP21
    16 Dimension of product 22.5*45*37mm



    Feature:

    1.Shell is made of high quality fire retardant PC material, up to the European environmental requirements, burning non-toxic.

    2.Inside Material is made of Tin phosphorous bronze, with good electrical conductivity, not easily deformed.

    3.Built-in automatic recovery fuse,more safe.

    4. Automatically adjust charging Wattage.

    5.USB charging interface, support more USB devices to charging at the same time.

    6.2100 MA output current,can reduce charging time.

    7.Compatibility: iPod, iPhone, iPad, Tablets, Mobile Phones, MP3 Bluetooth Headsets, GPS & more.

    Product show

    F8D

    Advantage

    1).Dual port USB charger of 2.1A 5VDC;

    2). Protection type: Short time short-circuit protection;

    3).With identifying chip: can automatically recognize different mobiles and suit its request charging AMP to meet the charging speed;

    4) IEC60950 FOR LVD and IEC55024,IEC61000 for EMC;

    5). All materials be ROHS directive tested

    4.Safety Warning:

    1.For indoor use only.

    2.This product must be installed/wired by a qualified electrician.



      5.Attentions:

    1.Protect children from touch skirt of USB port.

    2.Ensure current and voltage as rating current/voltage .Do not overload

    3.Prevent from corrosive liquid, gas (strong acid, strong alkali, paint)and humidity.
