Product Description
| Item No. | H-HDMI-20 |
| Type | HDMI Female to Female |
| Brand | Safewire |
| Material | ABS |
| Degree | 180° |
| Color | White/Black optional |
| Pin | 19-Pin Adapter Contact |
| Storage | -40℃to 70℃ |
| operation | -10℃ to 60℃ |
Feature
1.Gold plated connectors
2.Supports v1.2, v1.3, v1.4a, 720p, 1080I, 1080p, 3D, and HDCP; typical maximum distance for HDMI cable is 33 feet
3.HDMI (High Definition Multimedia Interface) connectors are ideal for connecting HD (High Definition) video, audio, home theatre systems, and computer equipment in commercial and residential applications
4.Due to space/port constraints within some of our 2/3/4/6/8/9/12 ports faceplates,we recommend for you to use the bottom port(s) for best fitting
5.Support 4K ultra HD video
Electrical:
· Current Rating: DC 1A.
· Withstanding Voltage: DC 300V, 10ms.
· Insulation Resistance: 10Mohm.
· Conductive Resistance: 2 Ohm.
Application:
This 180° high-definition multimedia interface (HDMI) keystone coupler modules (containing female connections on both sides) are ideal for customized high-definition video along with eight (8) channels of digital audio. They are a popular option for connecting high-definition televisions (HDTV) to Blu-ray players, and many other home entertainment devices. The coupler has female connectors on both ends to connect two HDMI cables.
RoHS Certificate of Compliance：Conforms with the Directive 2002/95/EC (ROHS)
The enclosures of all maintenance boxes shall be fabricated from halogen-free, non-toxic, and environmentally sustainable materials. Their corrosion resistance shall be capable of withstanding exposure to solutions with an acid concentration of 10% or an alkali concentration of 10% and above. The material shall exhibit a temperature stability range of no less than -40°C to +90°C, and its flame resistance temperature in the hot filament test shall not be lower than +960°C. It shall possess properties such as full insulation, dust resistance, water resistance, corrosion resistance, impact resistance, UV resistance, heat resistance, flame retardancy, shock resistance, and high mechanical strength.
Sectional maintenance boxes shall be made of polycarbonate material, which is characterized by corrosion resistance, halogen-free composition, flame retardancy, and self-extinguishing capability. The impact resistance rating shall meet IK09, and the box body shall be of an integrated design. Sealing bolts shall be provided for cable entry into the maintenance boxes, and sufficient space for incoming cables shall be considered. Sockets shall have high impact resistance and corrosion resistance; industrial connectors shall have a protection rating of IP67. Sockets and circuit breakers shall be mounted on the surface of the box body for ease of operation, with specific configurations detailed in the system diagram of the sectional maintenance boxes. The overall protection rating of the maintenance boxes shall reach IP66.
