safewire HTD-622AS/SS/SP

Short Description:


  • Port: Wenjiang
  • Product Detail

    Product Tags

    Model: HTD-626AS-86

    (Brand Name : Safewire or OEM brand

    Place of origin : Zhejiang ,Wenzhou,China

    Type:raised floor box

    Color :Black

    Voltage:95~260V                  Market standard: Customized Grounding:Standard grounding          Frequency:50Hz~60Hz

    HS Code:8536690000                  Current Type: AC



    Serial No. Parameter Description

    1

    Panel materials

    Plastic

    2

    Material

    ABS, galvanised steel

    3

    Overall Frame & Lid (mm)

    320.5*230.5

    4

    Compact floor cut-out(mm)

    (305-310)*(210-215)*(76-110)

    5

    Thickness of concavity/Frame lid recess (mm)

    8

    6

    Installation depth(mm)

    70mm~110mm

    7

    Plug top clearance(mm)

    13~38

    8

    Available modules

    3 dul BS socket(86*146mm)

    9

    Accessories plates

    90*80mm

    10

    G.W.

    14.2KG/Carton

    11

    N.W.

    13.2KG/Carton

    Application:

    Applicatio

    The raised floor feature

    1.Easy to repair the line, easy to replace the aging line.

     The raised floor feature

    2.Strong permeability, easy to use air conditioning and ventilation
     The raised floor feature2

    3.Easy to install, disassemble, reduce the cost of rewiring

     The raised floor feature3



    The raised floor to socket requirements:

    1.Environmental protection.

    2.Fire prevention/Corrosion resistant/high strength.

    3.Good interchangeability with raised floors.Easy to installation.

    4.The laying height of the floor is 35mm ~150mm



    Features:

    1. Optional floor:Applicable for access and concrete floor

    2. Safety lid:Frame &lid from ABS plastic ,static pressure over 1000N.

    3. Protected opening system: Easy grip recessed lifting handle.

    4. BS standard receptacle: screw fixing of three* twins 86 type or 6* 86*86

    switch socket bridge accessories.

    5. Cavity of floor: 8mm and lid is overlapping the edge of the floor.

    6.Adjustable height of bottom box:76~111mm.

    Remark: For concrete floor:

    To be with additional metal box item#BG-HTD626



    Product display:

    Product display

    HTD-626AS Outline drawing:

    HTD-626AS Outline drawing

    Installation instructions:

    Installation instructions

    1.Floor box(For concrete floor)

    2.Steel armored conduit(For trunking system/Access floor).

    3.Put under floor box into cut out and adjust height(For raised floor) .

    4.Installing Heavy current/Data systems

    5.Connecting and earthing.

    6.Assembly and plug into underfloor box.

    7.Single outlet

    Attentions:

    1.The sealing ring is closely attached to the smooth surface to prevent water leakage.

    2.When installing and wiring,Product should avoid direct contact with corrosive liquid, gas (strong acid, strong alkali, paint).

    3.Please close cover when not used.



    Safety Warning

    1.This is a class I product and must be earthed

    2.This product must be installed/wired by a qualified electrician

    3.For indoor use only.

    4.For concrete floor/access floor.base on different bottom box.



    Package:12 Pcs inner box into a master carton.Poly bag with box packing.
