ABS underfloor side mounted socket with 45type socket/raised floor socket

Short Description:




  • Port: Wenjiang
  • Technical Parameters

    Product Show:

    HTD-624C Outline drawing

    Product Tags

    Quick Details:

    Serial No. Parameter

    Description

    1

    Safewire item

    HTD-624C

    2

    Material

    ABS, galvanised steel

    3

    Overall Frame & Lid (mm)

    245*225

    4

    Compact floor cut-out(mm)

    (210-215)*(230-235)*(76-110)

    5

    Thickness of concavity/Frame lid recess (mm)

    8

    6

    Installation depth(mm)

    76~110

    7

    Plug top clearance(mm)

    13~48

    8

    Available modules

    12 modules

    9

    Accessories plates

    90*80mm

    Application:

    1.Feature of Safewire floorbox:

    1.More capacity:8,12,16,24 way 45*45mm modules ; or 3 compartments bridges:

    2.More optional switch & socket: International 45*45mm modules,86 type,120 type etc.

    3.More optional installation:Horizontal,Side-mounting, Side-mounting & Horizontal;

    4.More Optional surface with carpet/Marble .

    5.More optional box for raised floor or concrete floor: Galvanized box, Stainless steel box and plastic box etc.

    2.Advantage of Safewire floorbox :
