Working environment:
- The environment temperature:-5℃~/40℃
- The rated voltage：100V~~250V
- Rated current：10A、13A、16A、20A
| Serial No. | Parameter | Description |
| 1 | Panel Material | Brass alloy/Stainless steel |
| 2 | Surface finish | Wire drawing/Polishing/Spray painting |
| 3 | Panel Dimension(mm) | 210*140 |
| 4 | Cutout(mm) | 202×132 |
| 5 | Static pressure | 1000N |
| 6 | Horizontal mounting | Horizontal installation |
| 7 | Sink box Material | Steel+Zinc plated |
| 8 | Hinged lid thickness | 4MM |
| 9 | Base box dimension(mm) | 200*130*85 |
| 10 | Available modules | 146*86panel(mm) |
1.Cable Exit is customization
2.Cavity depth is customization
3.Knock-out diameter is customization
4.Configuration as twins switch socket as 146*86
5.Depth of bottom box is customization
The raised floor to socket requirements:
1.Environmental protection.
2.Fire prevention/Corrosion resistant/high strength.
3.Good interchangeability with raised floors.Easy to installation.
4.The laying height of the floor is 35mm ~150mm.
Concrete floor requirements for floor socket：
1、No pollution to the environment, no harm to the human body, no toxicity.
2、Easy to install and easy to use, not easy to damage.
The enclosures of all maintenance boxes shall be fabricated from halogen-free, non-toxic, and environmentally sustainable materials. Their corrosion resistance shall be capable of withstanding exposure to solutions with an acid concentration of 10% or an alkali concentration of 10% and above. The material shall exhibit a temperature stability range of no less than -40°C to +90°C, and its flame resistance temperature in the hot filament test shall not be lower than +960°C. It shall possess properties such as full insulation, dust resistance, water resistance, corrosion resistance, impact resistance, UV resistance, heat resistance, flame retardancy, shock resistance, and high mechanical strength.
Sectional maintenance boxes shall be made of polycarbonate material, which is characterized by corrosion resistance, halogen-free composition, flame retardancy, and self-extinguishing capability. The impact resistance rating shall meet IK09, and the box body shall be of an integrated design. Sealing bolts shall be provided for cable entry into the maintenance boxes, and sufficient space for incoming cables shall be considered. Sockets shall have high impact resistance and corrosion resistance; industrial connectors shall have a protection rating of IP67. Sockets and circuit breakers shall be mounted on the surface of the box body for ease of operation, with specific configurations detailed in the system diagram of the sectional maintenance boxes. The overall protection rating of the maintenance boxes shall reach IP66.
