Product Details
|
Serial No. |
Parameter |
Description |
| 1 | Type | RJ45 Jack+1.0M LAN cable |
| 2 | Material | ABS |
| 3 | Female RJ45 LAN Keystone | CAT5e,Unshielded ABS plastic RJ45 Jack/Jack;TIA/EIA:568A/B |
| 4 | Angle of female RJ45 LAN Keystone | 180° |
| 5 | Color of RJ45 LAN Keystone | White/Black optional |
| 6 | RJ45 LAN Keystone Material | Plating 50U is optional |
| 7 | LAN Cable with hook | The distance from the LAN connection completion position to the anti-bending area shall be 20 mm |
| 8 | Angle of male adaptor | 180° |
| 9 | LAN cable material | ABS |
| 10 | Length | 0.8~1M |
Drawing Line：
Features:
- CAT5e,Unshielded ABS plastic RJ45 Jack/Jack;TIA/EIA:568A/B.
- It maintains the same shape and HOOK as the USB KEYSTONE CABLE above.
- The distance from the LAN connection completion position to the anti-bending area shall be 20 mm.
Attentions:
1. Use in dry places only.
2.Please plug into cable completely.
3.For your safety, please don’t plug by wet hands.
4. This keystone and cable length is customization production.
The enclosures of all maintenance boxes shall be fabricated from halogen-free, non-toxic, and environmentally sustainable materials. Their corrosion resistance shall be capable of withstanding exposure to solutions with an acid concentration of 10% or an alkali concentration of 10% and above. The material shall exhibit a temperature stability range of no less than -40°C to +90°C, and its flame resistance temperature in the hot filament test shall not be lower than +960°C. It shall possess properties such as full insulation, dust resistance, water resistance, corrosion resistance, impact resistance, UV resistance, heat resistance, flame retardancy, shock resistance, and high mechanical strength.
Sectional maintenance boxes shall be made of polycarbonate material, which is characterized by corrosion resistance, halogen-free composition, flame retardancy, and self-extinguishing capability. The impact resistance rating shall meet IK09, and the box body shall be of an integrated design. Sealing bolts shall be provided for cable entry into the maintenance boxes, and sufficient space for incoming cables shall be considered. Sockets shall have high impact resistance and corrosion resistance; industrial connectors shall have a protection rating of IP67. Sockets and circuit breakers shall be mounted on the surface of the box body for ease of operation, with specific configurations detailed in the system diagram of the sectional maintenance boxes. The overall protection rating of the maintenance boxes shall reach IP66.
